IRB 2600 Data sheet.pdf

1. Overview

The ABB IRB 2600 is a high performance medium-sized industrial robot designed for medium-load applications with high precision and high speed. Its compact structure and flexible configuration make it suitable for a variety of industrial scenarios, including welding, material handling, assembly, painting and palletizing tasks. This series of robots is known for its high reliability and repeatability, and is especially suitable for space-constrained production environments.

ABB robot

2. Models and variants

The IRB 2600 series consists of several sub-models, the main differences being load capacity and operating range:

IRB 2600: Standard edition, load capacity 12-20 kg, maximum working range 1.65-1.85 m.

IRB 2600ID (Integrated Pipeline Version) : Built-in cable conduit to reduce peripheral pipeline interference, suitable for complex paths (such as arc welding, glue).

Long arm version (optional) : Extended operating range to 2.0 m, suitable for a wide range of operating scenarios.

3. Core design features

Compact construction: The body is narrow (only 220 mm width), suitable for dense production lines or small Spaces.

Six axis degrees of freedom: Flexible movement, can adapt to complex trajectories (such as 3D curve welding).

Protection class: IP67 or optional IP69K (anti-high pressure cleaning), suitable for wet, dust environment (such as food processing, casting).

Lightweight design: Magnesium aluminum alloy, reduce inertia, improve speed and energy efficiency.

ABB robot

4. Performance parameters

                         Parameter                                                      Value/Capability

                      Maximum load                                      12-30 kg (depending on model)

                       Working range                                                      1.65-2.0 m

         Repeated positioning accuracy                                    ±0.05 - ± 0.1mm

                Maximum speed axis                                        1:180 °/s, axis 6:240 °/s

                     Installation mode                               Ground, upside down, wall hanging, tilt

5. Typical application areas

Welding: arc welding, spot welding (IRB 2600ID built-in cable to reduce wear).

Material handling: high-speed pickup and placement (electronic components, food packaging).

Spraying and gluing: high-precision path control (automotive sealant, furniture painting).

Assembly: Precision component assembly (e.g. engine, battery module).

Palletizing: Supports dynamic pallet positioning and ADAPTS to diverse packaging specifications.
